pxd Series

PXD Series Low Clearance Hydraulic Torque Wrenches

PXD Series Download Catalog

Technical Data
Model No. PXD-0.75 PXD-1 PXD-1.5 PXD-2 PXD-4 PXD-8 PXD-16 PXD-32 PXD-45
Tool Hex
from
13mm /
½”
13mm /
1/2”
19mm/
¾”
19mm /
3/4”
25mm /
1”
50mm /
1.7/8
65mm /
2.5/8”
80mm /
3.1/8”
80mm /
2.7/16”
to 41mm /
1.5/8”
46mm /
1.13/16”
46mm /
1.13/16”
60mm /
2.3/8”
80mm /
3.1/8”
105mm /
4”
115mm /
4.5/8”
155mm /
6.1/8”
155mm /
6.1/8”
Min. Torque
Kg-m (Ft/Lbs)
5.6
(41)
6
(45)
14
(100)
26
(192)
54
(395)
115
(830)
245
(1,560)
445
(3,220)
658
(4,865)
Max. Torque
Kg-m (Ft/Lbs)
68
(490)
77
(560)
137
(995)
260
(1,928)
540
(3,950)
1192
(8,630)
2293
(16,600)
4924
(35,650)
6410
(47,380)
Output Accuracy +/-3% +/- 3% +/-3% +/- 3% +/- 3% +/- 3% +/- 3% +/- 3% +/- 3%
Repeatability 100% 100% 100% 100% 100% 100% 100% 100% 100%
Duty Cycle 100% 100% 100% 100% 100% 100% 100% 100% 100%
Corrosion Protection Standard
Cylinder Weight
Kgs / (Lbs)
0.38 /
(0.84)
0.50 /
(1)
0.55 /
(1.2)
1.59 /
(3.50)
2.73 /
(6.00)
5.32 /
(11.70)
7.27 /
(16.00)
11.82 /
(26.00)
13.7/
(30.2)
Link Weight
from Kgs / (Lbs)
0.47 /
(1)
0.50 /
(1)
0.60 /
(1.3)
1.09 /
(2.40)
2.45 /
(5.40)
5.41 /
(11.90)
9.55 /
(21.00)
13.18 /
(29.00)
13.18 /
(29.00)
to Kgs / (Lbs) 0.47 /
(1)
0.50 /
(1)
0.90 /
(2.0)
1.59 /
(3.50)
3.45 /
(7.60)
6.59 /
(14.50)
12.73 /
(2.00)
17.95 /
(39.50)
17.95 /
(39.50)

PXD Series Specifications

Dimensions
Model No. PXD-0.75 PXD-1 PXD-1.5 PXD-2 PXD-4 PXD-8 PXD-16 PXD-32 PXD-45
mm inch mm inch mm inch mm inch mm inch mm inch mm inch mm inch mm inch
Length 108.00 4.25 111.00 4.37 107.00 4.20 167.00 6.57 203.20 8.00 253.00 9.96 330.00 13.00 390.00 15.35 450.00 17.71
Height 82.60 3.25 82.60 3.25 87.00 3.40 103.00 4.05 144.00 5.66 179.50 7.06 193.80 7.63 278.00 10.94 278.00 10.94
Width1 18.00 0.70 20.40 0.80 28.00 1.10 31.80 1.25 41.80 1.64 52.40 2.06 64.00 2.51 82.35 3.24 82.35 3.24
Width2 18.00 0.70 24.25 0.95 28.00 1.10 38.00 1.49 47.40 1.86 58.00 2.28 70.00 2.75 92.00 3.62 124.00 4.88
Radius 5.80 0.23 5.80 0.23 7.50 0.30 9.30 0.36 11.85 0.46 13.90 0.54 16.80 0.66 23.75 0.94 23.75 0.94
