Electric Torque Wrench ELECTRO ETWC Series
Download CatalogThe ETWC Series Torque Wrench is a hand held, non-impacting electrically driven power tool designed to apply higher torque values. The tool is designed to deliver a preset torque load. Efficient, safe, and fast operation makes it suitable for heavy duty bolting applications.
Features
- Ease of Operation - The wrench stops after the set torque values are achieved.
- Smooth Operation - The wrench is designed for smooth running without any impact.
- Wide Range - Wide range of torque power from 150 Nm. to 4200 Nm. covered in four models.
- Accurate and Convenient - Light weight, ergonomically designed tool and electronically controlled cut-off system ensure repeatability of torque value.
- High Performance Gearbox - High performance alloy steel gears with impact free loading ensure long life and high accuracy performance.
- Single Phase Supply - Power required for the tool is readily available, single phase 230V - 50Hz.
Technical Details
| Model | Min. Torque | Max. Torque | Free Speed | Sq. Size | Weight with Reaction Arm | |||
|---|---|---|---|---|---|---|---|---|
| Lb.ft | Nm | Lb.ft | Nm | rpm | inch | kg | ||
| ETW-50 | 110 | 150 | 479 | 650 | 25 | 3/4" | 6.8 | |
| ETW-100 | 221 | 300 | 1106 | 1500 | 9 | 1" | 7.3 | |
| ETW-200 | 553 | 750 | 2212 | 3000 | 4.5 | 1" | 9.8 | |
| ETW-300 | 811 | 1100 | 3097 | 4200 | 1.7 | 1.1/2" | 12.6 | |
